street light is a green product of our company, with new type integrated LED light source, high purity aluminum plating reflector, high thermal conductivity aluminum lamp shell and radiating body, High strength toughened glass cover, high efficient constant pressure constant current；Compared with the traditional street light, ST702-80/140W has lots of unique features, such as more efficient, energy-saving, more security and environmental, long lifespan, quicker response and higher CRI. ST702-80/140W could be used in the street, square, city, scenery area and so on. It will be the best to replace traditional high pressure street light, besides, it’s also the best choice to light Square, school Personal garden and so on.
Using cob LED chip , no glare , smooth and uniformity of luminance. With tempered glass lens, high light tran
Using air convection to help dissipate heat, the best cooling method
High quality LED driver , high efficency, wide input voltage from 85-265 v, PF >0.98 , constant current and volatage output, safe and stable.
Technical Parameters
Ø Power parameters
| Power | 80W | 100W | 120W | 140W |
| Input Voltage/Frequency | 100-240VAC/50-60Hz |
| Input Current(Typ) | ≤1.32A/115VAC ≤ 0.66A/230VAC |
| Output Voltage | 28-36V Typ=30V |
| Output Current | 2.66A | 3.33A | 4.00A | 4.66A |
| Efficiency(Typ) | ≥85% |
| Power Factor(Typ) | PF≥0.98/115VAC PF≥0.95/230VAC |
Ø Lighting parameters
| LED Chips Quantity LED | 2 Pcs |
| LED Consumption LED | 80W | 100W | 120W | 140W |
| System Consumption | 89W | 110W | 132W | 152W |
| LED Luminous Efficiency LED | 85-110Lm /W |
| Lamp’s Initial Flux | ≥6640lm | ≥8500lm | ≥10200lm | ≥11800lm |
| Color Temperature | 2700K～7000K Typ=5500K |
| Lamp’s Luminous Efficiency | ≥85Lm /W |
| Lumen Maintenance | 70%(50000Hrs) |
| Color Rendering Index | Ra≥70 |
| Light Distribution | Please refer to the attachment test report | Daniell |
| Operating Temperature | -25℃ ～ +55℃ |
| Storage Temperature | -25℃ ～ +65℃ |
| IP Grade | IP65 |
| Life-span | 50000Hrs |
| Materials | Aluminum |
| The color of the lamp shell | White gray |
| Mounting | Pole installation |
Note: Light optic with a little deviation for different color temperature LED ,deviation value≤5%
